The AN-Q21 Grid Parabolic Antenna is a high-performance directional antenna designed for 4G/5G CPE applications in remote and signal-challenged areas like mountains and suburbs. Operating across 1710-2700 MHz and 3300-4200 MHz bands, it delivers dual-polarized (±45°/V+H) signals with high gain (19dBi/21dBi) and narrow beamwidth (10°–15°) for focused, long-distance coverage. Its rugged grid parabolic design ensures durability against 60 m/s winds, while the compact 0.3×0.4m size and lightweight construction reduce shipping costs. Compatible with N-type connectors (or customizable options), it’s ideal for extending network reach in rural or industrial deployments.
ELECTRICAL | ||
Model | AN-Q21 | |
Frequency Range | 1710-2700-MHz | 3300-4200-MHz |
Bandwidth | 700-MHz | 900-MHz |
Gain | 2*19dBi | 2*21dBi |
Beamwidth | H: 12° E: 15° | H: 10° E: 13° |
F/B Ratio | ≥20-dB | ≥20-dB |
VSWR | ≤2 | ≤2 |
Polarization | ±45 or V+H | ±45 or V+H |
Max power | 100 -W | |
Nominal Impedance | 50 -Ω | |
MECHANICAL | |
Connector | 2*N or N female or customized |
Antenna Dimension | 0.3x0.4-M |
Weight | /-Kg |
Rated Wind Velocity | 60-m/s |
Diameter of the Pole | Φ40~50-mm |
Wide Frequency Range: Supports 1710–2700 MHz (4G) and 3300–4200 MHz (5G) for future-proof use.
High Gain & Precision: 19dBi/21dBi gain with 12°–15° beamwidth minimizes interference.
Durable Build: Grid parabolic reflector withstands harsh weather (60 m/s wind) and UV exposure.
Easy Installation: Includes L-shaped brackets, hoops, and screws for quick pole mounting (Φ40–50mm).
Low VSWR: ≤2.0 ensures efficient signal transmission with 50Ω impedance.
Cost-Effective: Lightweight design reduces shipping costs vs. solid parabolic antennas.
Versatile Use: Ideal for CPE devices, fixed wireless access, and backhaul links.
