S1 5G CPE delivers exceptional WiFi 6 performance with advanced 802.11ax technology, enabling high-speed networking. Powered by MT7621A + MT7905DAN + MT7975DN chipsets, it achieves 1800Mbps wireless speeds, supporting 5G internet, 11AX protocol, firewall & IPv6 for efficiency and security.
Featuring dual-band antennas (2.4G: 2.412~2.4835GHz / 5.8G: 5.150~5.250GHz & 5.725~5.825GHz), it ensures stable signals in any environment. With Sub-6G support, it hits 2Gbps DL / 1Gbps UL speeds, ideal for data-intensive tasks.
Flexible connectivity via SIM/eSIM (optional), Gigabit WAN/LAN ports, and multi-VPN client support adapts to diverse scenarios. 5G NR (n1/n28/n41/n78/n79) + LTE/WCDMA multi-band coverage guarantees reliability in rural, mobile (ships/cars/trains), or harsh conditions.
For enterprises, it offers AP/Router/Repeater modes, firewall/blacklist management, Mesh networking, and seamless roaming—reducing IT costs while boosting security. Smart features like guest WiFi, parental controls, web-based UI, and load balancing simplify management.
From smart homes to remote work, S1 5G CPE redefines connectivity with industrial-grade reliability, ultra-fast 5G WiFi, and cross-scenario adaptability—delivering speed, security, and stability everywhere.
| Parameter | Specification |
| Chip Solution | MT7621A+MT7905DAN（2.4G 5.8G 2T2R）+MT7975DN（FEM） |
| 5G NR | n1/n28/n41/n78/n79 |
| LTE& WCDMA | B1/B3/B5/B8/B34/B38/B39/B40/B41 WCDMA:B1/B8 |
| Main features | 5G internet, 11AX protocol, firewall, IPV6、eSIM |
| FLASH/FLASH / Memory | 1Gbit NAND Flash/256MByte DDR3 |
| Antenna | 2.4G: 2T2R 5.8G: 2T2R |
| Interface | 1 M.2 Interface for 5G |
| Frequency Range | 2.4G:2.412~2.4835GHz、5.8G:5.150GHz~5.250GHz 5.7250GHz~5.8250GHz |
| Wireless rate | 11ax: Max1800Mbps |
| Data modulation method | 802.11ax: OFDM (BPSK, QPSK,16-QAM, 64-QAM, 256-QAM,1024-QAM) |
| Network Function | 5G:Sub-6G(100M) Downlink 2 Gbps Uplink1 Gbps |
| SIM card | support SIM (4FF nano),optional :eSIM |
| Internet port | 10 / 100 / 1000Mbps adaptive eight pin RJ45 * 3 (LAN * 2 + WAN / LAN configurable port * 1) |
| main function | 11AX wireless access |
| IPv6 | Four IPv6 networking modes: relay mode, static IP, dynamic IP, and broadband connection. IPv6 is disabled by default |
| VPN Client | two types of VPN client configurations: PPTP and L2TP |
| MESH | Enable settings, character settings, mesh connection topology |
| Important remarks | Mobile network (5G/4G) access, Ethernet access, 5GHz optimization, SMS service, firewall, pin protection, MAC address filtering, WiFi encryption authentication, VPN tunnel /vpn penetration, IPv6 and ipv6/ipv4 dual stack only, multiple APNs,webui, FOTA upgrade, etc |
| For rural and mountainous areas | |
| For mobile carriages, like ships, automobiles and trains | |
| For those places where hardwire-line telephone service is unavailable | |
Powerful Chipset Solution
Featuring an advanced MT7621A + MT7905DAN (2.4G & 5.8G 2T2R) + MT7975DN
(FEM) chipset combination, delivering high-performance routing capabilities.
Extensive Network Band Support
5G NR bands: Supports n1/n28/n41/n78/n79 to meet 5G requirements across regions
LTE & WCDMA bands: LTE supports B1/B3/B5/B8/B34/B38/B39/B40/B41; WCDMA •supports B1/B8, ensuring compatibility with various 4G/3G networks
Advanced Communication Protocols & Technologies
5G internet support for high-speed connectivity
11AX (Wi-Fi 6) protocol delivering up to 1800Mbps wireless speeds
Supports multiple OFDM modulation schemes including BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM and 1024-QAM for optimal performance
Rich Interfaces & Storage
1 M.2 interface for 5G module or storage expansion
1-bit NAND flash + 256MB DDR3 memory for stable operation
Versatile Connectivity Options
Antenna: 2T2R configuration for both 2.4G/5.8G bands
Ports: 3×10/100/1000Mbps RJ45 ports (2×LAN + 1×configurable WAN/LAN)
SIM: Supports 4FF nano-SIM with optional eSIM
IPv6: Supports relay/static IP/dynamic IP/PPPoE modes
VPN: PPTP & L2TP client support
Comprehensive Features & Protection
Dual WAN (5G/4G + Ethernet)
5GHz optimization
SMS service, firewall, PIN protection, MAC filtering
VPN tunneling/passthrough
IPv6/IPv4 dual-stack
Multi-APN configuration
WebUI management
FOTA updates
Wide Application Scenarios
Remote/rural/mountainous areas
Mobile environments (ships/vehicles/trains)
