Operates across 1710–4200MHz frequency range, supporting wide 5G coverage.
2490MHz bandwidth to ensure stable and efficient signal transmission.
High antenna gain of 27dBi delivers enhanced signal strength and reach.
Narrow beamwidth design: 5° horizontal and 3° vertical for precise coverage.
Front-to-back ratio ≥30dB reduces interference and improves link quality.
VSWR ≤2.0 ensures low signal reflection and higher transmission efficiency.
Maximum power handling capacity up to 100W.
Standard 50Ω impedance ensures compatibility with most RF systems.
Equipped with dual N-female connectors, customization available.
Antenna dimension 60×90cm, optimized for outdoor installation.
Withstands wind speeds up to 60m/s, ensuring durability in harsh environments.
Mounting pole diameter supported: 50–75mm.
| ELECTRICAL | |
| Model | AN-Q90 |
| Frequency Range | 1710-4200MHz |
| Bandwidth | 2490MHz |
| Gain | 27 dBi |
| Beamwidth | H：5° E：3° |
| F/B Ratio | ≥30 dB |
| VSWR | ≤2.0 |
| Polarization | Vertical or Horizontal |
| Max power | 100 -W |
| Nominal Impedance | 50 -Ω |
| MECHANICAL | |
| Connector | 2*N female or Customized |
| Antenna Dimension | 60*90 CM |
| Rated Wind Velocity | 60-m/s |
| Diameter of the Pole | Φ50~75-mm |
