Powered by Qualcomm X62 modem, compliant with 3GPP Release 16.
Reaches peak downlink speeds of 2.5Gbps and uplink speeds of 0.9Gbps.
Supports dual-band Wi-Fi 6 (2.4GHz & 5.8GHz) with throughput up to 2400Mbps.
Offers one Gigabit WAN/LAN combo port plus two Gigabit LAN ports.
Equipped with 4 LTE/NR antennas and 4 Wi-Fi antennas for stronger coverage.
BandLock – Fixes the router on a chosen frequency band for steady performance.
CellLock – Prevents unnecessary cell tower switching, ensuring stable signal quality.
AT Commands – Enables direct module configuration and control.
IMEI Change – Allows modification for testing or carrier integration.
IP Passthrough – Assigns public IP directly to a connected LAN device.
VPN – Secures data traffic and supports remote private connections.
Explore the benefits and request a quote for the SUNCOMM 5G router by contacting us today!
| Technical Parameters | ||||
| Model： | SE06 | |||
| 5G Module： | RM520N-GL | |||
| Ethernet: | 1* WAN/LAN 1Gbps 2* LAN 1Gbps 2* Nano SIM card slots | |||
| 5G NR： (SE06) | NSA/SA: N1/ N2/ N3/ N5/ N7/ N8/ N12/ N13/ N14/ N18/ N20/ N25/ N26/ N28/ N29/ N30/ N38/ N40/ N41/ N48/ N66/ N70/ N71/ N75/ N76/ N77/ N78/ N79 | |||
| LTE-FDD: B1/ B2/ B3/ B4/ B5/ B7/ B8/ B12/ B13/ B14/ B17/ B18/ B19/ B20/ B25/ B26/ B28/ B29/ B30/ B32/ B66/ B71 | ||||
| LTE-TDD: B34/ B38/ B39/ B40/ B41/ B42/ B43/ B48 | ||||
| LTE-LAA: B46 | ||||
| WCDMA: B1/ B2/ B4/ B5/ B8/ B19 | ||||
| Data Rate | 5G SA Sub-6 | DL 2.4 Gbps; UL 900 Mbps | ||
| 5G NSA Sub-6 | DL 3.4 Gbps; UL 550 Mbps | |||
| LTE | DL 1.6 Gbps; UL 200 Mbps | |||
| WCDMA | DL 42 Mbps; UL 5.76 Mbps | |||
| Performance paremeter | ||||
| CPU | MT7981BA+MT7976CN+MT7531AE（Dual-core A53 1.3GHz） | |||
| WiFi 6 | 2.4G / 5G ，2.4GHz 2TR :600Mbps , 5GHz 2T2R :2402Mbps | |||
| Storage | 512MB DDR3 + 128MB SPI NAND FLASH | |||
| WiFi Standard | IEEE 802.11b、g、a、n、ac、ax，IEEE 802.3、u、x | |||
| Working mode | Router / Bridge | |||
| Wireless security | Wireless MAC address filtering 64/128 bit WEP encryption WPA-PSK、WPA2-PSK、WPA3-SAE、WPA/WPA2-PSK 、WPA2-PSK/WPA3-SAE WPS(PBC) | |||
| Other features | Wireless host status display | |||
| Wireless site scanning | ||||
| Seamless roaming between nodes | ||||
| Seamless roaming between bands | ||||
| WiFi settings | WiFi basic settings (dual-band integration, switch, wireless mode, SSID, PWD, encryption algorithm, channel, bandwidth, power adjustment). | |||
| Advanced settings (wireless client isolation, 802.11h, WMM multimedia acceleration). | ||||
| Multiple SSIDs (SSIDs, encryption methods, PWDs, and encryption algorithms) | ||||
| Button | Mesh (press 1 second). | |||
| Reset (press and hold for 5 seconds). | ||||
| LED Indicator | 5G, 4G, WIFI signal indicator, power indicator | |||
| Power supply | DC 12V/2A | |||
| Network settings | Data Switch, Roaming Switch, Mode Selection, Default APN Information, and APN Manual Configuration | |||
| FAILOVER switches: PPPOE, DHCP, and static | ||||
| 4G/5G band locking | ||||
| WiFi settings | WiFi name and password, wifi timing, channel bandwidth setting, power regulation, bridging function, OFDMA, Mesh | |||
| SMS feature | SMS sending and receiving, SMS center settings, USSD | |||
| Guest network | Configure the SSID, rate limit, and startup time limit of the guest network | |||
| Parental controls | Online device display, online time, restricted Internet time period, URL filtering configuration | |||
| Advanced settings | Working Mode, SIM PIN, Mobile Data Switch, Bandwidth Control, Sleep Mode, LED Control, Filter MAC Address, Firewall, Static Routing, DDNS, Virtual Server, DMZ Host, UPnP, TR069 Settings, VPN(L2TP/PPTP/Wireguard/GRE/IPsec/OpenVpn),IMEI Modify,Zerotier,Smart QoS,Firewall, Domain ACL,UPnP,Remote web | |||
| System settings | System Status, Time Setting, Password Management, Configuration Management, Firmware Upgrade, Scheduled Restart, System Log, LAN Setting, DHCP Binding, Reboot & Reset, Remote Management | |||
| Use environment | Operating temperature: -20°C to 50°C | |||
| Storage temperature: -40°C to 70°C | ||||
| Operating humidity: 10% to 90% RH non-condensing | ||||
| Storage humidity: 5% to 95% RH non-condensing | ||||
