Integrated VoIP/VoLTE with RJ11 port enables high-quality internet voice calling, combining data and telephony in one device.
Supports 4G LTE CAT4 with speeds up to 150Mbps downlink and 50Mbps uplink for fast and stable internet.
Compatible with FDD-LTE, TDD-LTE, and WCDMA networks, ensuring wide coverage and flexible deployment.
Equipped with ASR1803 chipset, 1Gb memory, and DL 2x2 MIMO to enhance performance and stability.
Includes WAN/LAN adaptive port, internal USB, LED indicators, and optional 2920mAh battery for portable use.
Supports IPv4/IPv6, firewall, MAC/IP filtering, Wi-Fi access control, and VPN (PPTP/L2TP/IPSec).
Feel free to contact SUNCOMM 4G router supplier for more solutions.
| Professional testing standards guarantee the quality experience of customers. | ||
| Basic Information | Dimension | About 165*115*40mm |
| Weight | About 158g (without battery) | |
| Color | White | |
| Air Interface | Technical Standard | Compatible with FDD-LTE |
| Frequency | LTE FDD: B1/B3/B5/B7/B8/B20/28 LTE TDD: B38/40/41 WCDMA: B1/B5/B8 | |
| Performance | Maximum Data Throughput | LTE CAT 4 FDD-LTE 150Mbps/50Mbps |
| Hardware | Receive Diversity | Support |
| MIMO | Support DL 2x2 MIMO | |
| BB Chipset | ASR1803 + PM803 | |
| Memory | 1Gb | |
| Power Consumption | <12W | |
| Power Voltage | DC12V/1A | |
| USIM/SIM | 2FF SIM card support SIM/USIM/UIM,standard 6 PIN SIM card interface, support 3V SIM card and 1.8V SIM card;internal | |
| LED | Power Indication LED WAN Signal Strength WAN/LAN Status LED Internet Status LED | |
| USB | 1*USB (Internal) | |
| Antenna | 2*External LTE Antennas | |
| Buttons | Reset/WPS, Power | |
| Ethernet | 1*WAN/LAN Port, 10BaseT/100Base automatic adaptive port | |
| RJ11 | 1*RJ11，can support VOLTE | |
| Battery | 2920mAh (Optional) | |
| ESD | ESD Protection circuit; Contact±6KV, Air±10KV | |
| Software | SW Update | TR069 & Local Update/FOTA |
| Voice | VoLTE/VoIP | |
| IPV4/IPV6 | Support | |
| Firewall | Mac/IP address filter, Port forwarding, Wi-Fi Black/White list | |
| Data Statistics | Support | |
| VPN | PP2P/L2TP/IPSec | |
| Environment | Operating Temperature | Normal: 0℃ ~ +40℃ |
| Storage Temperature | -10°C ~ +60°C | |
| Humidity | 5%~ 95% | |
