Built on Qualcomm's SDX65 platform and supports 3GPP Release 16, offering up to 4.9Gbps download and 0.9Gbps upload speeds.
Features Qualcomm Wi-Fi 6 on 2.4GHz and 5.8GHz, offering speeds up to 3Gbps.
Offers a 2.5G WAN/LAN port plus one gigabit LAN ports to support high-speed networking.
Supports voice communication by providing an RJ11 port for phone connection.
Includes 8 internal high-gain antennas for LTE/NR and 2 for Wi-Fi, with smart antenna selection and support for 2 external TS9 antennas.
BandLock: keeps the router on one network band for a more stable connection.
CellLock: lets you fix the router to a specific cell tower for more stable signal.
AT Commands: allow users to control modem functions manually for advanced settings.
IMEI Change: helps with network access or device simulation when needed.
IP Passthrough: Allows one device to receive the public IP from the router.
VPN: Allows encrypted access to remote networks
| Technical Standard | Compatible with LTE, Sub6, 802.11 a/b/g/n/ac/ax |
| Frequency (EA) | EA version: 5G: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n75/n77/n78 LTE: B1/B3/B5/B7/B8/B20/B28/B32/B38/B40/B41/B42/B43 UMTS: B1/B5/B8 |
| Frequency (SA) | SA version: 5G: n2/n5/n7/n8/n12/n13/n28/n66/n38/n40/n41/n77/n78 LTE: B2/B4/B5/B7/B8/B12/B13/B28/B66/B38/B40/B41/B42/B43 UMTS: B2/B4/B5/B8 |
| Frequency (NA) | NA version: 5G: n2/n5/n12/n 13/n14/n25/n26/n29/n30/n41/n48/n66/n71/n77/n78 LTE: B2/B4/B5/B12/B13/B14/B25/B26/B29/B30/B41/B42/B43/B48/B66/B71 UMTS: B1/B2/B4/B5/B8 |
| WIFI | 2.4GHz&5.8GHz, WIFI 2*2 MIMO, 802.11 a/b/g/n/ac/ax, DBDC AX3000 |
| Maximum Data Throughput | 5G SA NSA mode • 5G NR: (DL/UL) 4.9Gbps/900Mbps • LTE: (DL/UL) 1.6Gbps/200Mbps |
| Receive Diversity | Support Receive Diversity |
| MIMO | DL 4x4 MIMO |
| Chipset | Qualcomm SDX65+WCN6856 |
| Memory | Modem: 8+8Gbit |
| Power Consumption | <18W |
| Power Voltage | DC12V/1.5A |
| USIM/SIM | 4FF SIM card support SIM/USIM/UIM, standard 6 PIN SIM card interface, support 3V SIM card and 1.8V SIM card; internal push-pull SIM slot |
| LED | Power Indication; Wi-Fi Indication; 5G Indication LED; 4G Indication LED |
| USB | USB 2.0 |
| Antenna | LTE/NR Antenna*8, Wi-Fi*2 , N41/77/78/79 11dBi High Gain, Smart antenna selection, 2*TS-9 external antenna is optional (support band n38/n40/n41/n77/n78) |
| Buttons | POWER, Reset, WPS |
| Ethernet | 1*WAN+1*LAN • 2*1000Base automatic adaptive port (default) • 1*2.5Gbps + 1*1Gbps port (optional) |
| VOICE | 1*RJ11, support VOIP/VOLTE/VONR(optional) |
| Reset | Pinhole |
| ESD | ESD Protection circuit; Contact±8KV, Air±10KV |
| HTTP | Support |
| Operating Temperature | Normal: 0℃~ +45℃ |
| Storage Temperature | -20℃ ~ +70℃ |
| Humidity | 5%~ 95% |
5G LTE
4.9Gbps/0.9Gbps
Wi-Fi 6
802.11 a/b/g/n/ac/ax, DBDC
Up to 3Gbps
Ethernet
10BaseT/100Base/1000Base automatic adaptive port 2.5Gbps Port for high speed user
RJ11
Connect to the telephone
