Powered by SDX75 from Qualcomm with 3GPP Release 17 support, delivering fast 6Gbps downlink and 0.9Gbps uplink.
Dual-band Wi-Fi 6 from Qualcomm delivers up to 6.4Gbps on 2.4GHz and 5.8GHz.
Features one 2.5G WAN/LAN shared port alongside one gigabit LAN ports for reliable speeds.
Allows connection of standard telephones via RJ11 port for voice calls.
Offers internal smart antenna switching across 6 LTE/NR and 2 Wi-Fi antennas; two TS9 connectors allow external antenna use.
BandLock: Prevents automatic band switching for a smoother online experience.
CellLock: Avoid signal drops by locking the router to the best-performing tower.
AT Commands: Use AT commands to fine-tune your router's network behavior.
IMEI Change: Useful for developers needing to simulate different device identities.
IP Passthrough: Gives your PC or server the router's external IP address.
VPN: Protects online activity by masking IP and encrypting traffic.
SUNCOMM ensures that our 5G CPE device series meets the highest standards of quality and performance.
| Technical Standard | Compatible with LTE, Sub6, 802.11 a/b/g/n/ac/ax/be |
| Frequency (EA) | EA version: |
| [5G NR]: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n71/n75/n76/n77/n78/n79 | |
| [LTE]: B1/B3/B5/B7/B8/B20/B28/B32/B38/B40/B41/B42/B43/B71 | |
| [UMTS]: B1/B3/5/8 | |
| Frequency (SA) | SA version: |
| [5G NR]: n2/n5/n7/n8/n12/n13/n28/n38/n40/n41/n66/n77/n78 | |
| [LTE]: B2/B4/B5/B7/B8/B12/B13/B28/B38/B40/B41/B42/B43/B66 | |
| [UMTS]: B2/B4/B5/B8 | |
| Frequency (NA) | NA version: |
| [5G NR]: n2/n5/n12/n13/n14/n25/n26/n29/n30/n41/n48/n66/n71/n77/n78 | |
| [LTE]: B2/B4/B5/B12/B13/B14/B25/B26/B29/B30/B41/B42/B43/B48/B66/B71 | |
| [UMTS]: B1/B2/B4/B5/B8 | |
| WIFI | WiFi7 |
| 2.4GHz&5GHz, WIFI 4*4 MIMO, 802.11 a/b/g/n/ac/ax/be, DBDC be7200, user 256 | |
| 2.4GHz&5GHz&6GHz, WIFI 4*4 MIMO, 802.11 a/b/g/n/ac/ax/be, DBDC be11000(optional), user 256 | |
| Easy mesh R4 is supported | |
| Maximum Data Throughput | 5G SA NSA mode |
| • 5G NR: (DL/UL) 6Gbps/900Mbps | |
| • LTE: (DL/UL) 1.6Gbps/200Mbps | |
| Receive Diversity | Support Receive Diversity |
| MIMO | DL 4x4 MIMO |
| Chipset | Qualcomm SDX72 |
| Memory | Modem: 16GB emmc+8Gb LPDDR4 |
| Power Consumption | <24W |
| Power Voltage | DC12V/2A |
| USIM/SIM | 4FF SIM card |
| support SIM/USIM/UIM, standard 6 PIN SIM card interface, | |
| support 3V SIM card and 1.8V SIM card; internal push-pull SIM slot | |
| LED | Power Indication; Wi-Fi Indication; 5G Indication LED; 4G Indication LED |
| USB | USB 2.0 |
| Antenna | LTE/NR Antenna*6, Wi-Fi*2, N41/77/78/79 8dBi High Gain, Smart antenna selection, |
| 2*TS-9 external antenna is optional (support band n38/n40/n41/n77/n78), WIFI 4 antenna is optional | |
| Buttons | POWER, Reset, WPS (easy mesh) |
| Ethernet | 1*WAN+1*LAN |
| • 2*1000Base automatic adaptive port (default) | |
| • 1*2.5Gbps + 1*1Gbps port (optional) | |
| VOICE | • 1*RJ11, support VOIP/VOLTE/VONR (optional) |
| Reset | Pinhole |
| NFC | Supported NFC to connect Wi-Fi |
| Battery | Not support, can choose UPS power |
| ESD | ESD Protection circuit; Contact±8KV, Air±10KV |
| HTTP | Support |
| Operating Temperature | Normal: 0℃~ +45℃ |
| Storage Temperature | -20℃ ~ +70℃ |
| Humidity | 5%~ 95% |
5G LTE
3GPP Release 17 6Gbps/0.9Gbps
Wi-Fi 7
802.11 a/b/g/n/ac/ax/be, DBDC 7.2Gbps Easy mesh R4
Ethernet
10BaseT/100Base/1000Base automatic adaptive port 2.5Gbps Port for high speed user
RJ11
Connect to the telephone
